Leírás és Paraméterek
Memory
16GB GDDR6, 256bit, 20Gbps, 2500MHz, 640GB/?s
clock Base
unknown
clock Boost
2400-2970MHz (Standard-Profile), 2460-3010MHz (OC-Profile)
overclock
+40MHz Boost (OC-Profile), +60MHz Game (OC-Profile)
Cooling
3x Axial-fan (100mm) with 0dB-zero-fan-mode (up to 60°C)
TDP/TGP
304W (AMD), max. 317W (PowerColor) [Silent-BIOS: 304W]
AI-Computing power
1557 TOPS (INT4 sparse), 778.5 TOPS (INT4 dense), 778.5 TOPS (INT8 sparse), 389.25 TOPS (INT8 dense)
GPU-Computing power
98.63 TFLOPS (FP16), 49.32 TFLOPS (FP32), 3.08 TFLOPS (FP64)
Power connections
2x 8-Pin PCIe
Connectors
1x HDMI 2.1b, 3x DisplayPort 2.1a UHBR13.5
Interface
PCIe 5.0 x16
Special features
Taktprofile (STD Mode/?OC Mode), LED lighting (RGB), Backplate, Dual BIOS switch
total height
Triple Slot (2.5 Slots)
Dimensions
327x128x49mm (LxWxH)
Type
PCIe card (full height)
PCI slot bracket
full height
Wärmeleitmaterial (TIM)
Honeywell PTM7950
Chip-data
Chip-Architecture
RDNA 4 (from 2025/?Q1)
Chip-title
Navi 48 XTX
Chip-Configuration
64CU (4096SP /? 256TMU /? 128ROP), 64 RT Cores, 64MiB L3 cache
Chip-Manufacturing Process
TSMC 5nm "N4P"
Chip size
357mm2, monolithisch, 53.9 Mrd. Transistoren
Chip-functions
Raytracing, AMD Infinity cache (64MiB), HDCP 2.3
API-support
DirectX 12 Ultimate (12_2) /? Vulkan 1.3 /? OpenCL 2.2 /? OpenGL 4.6 /? Shader Model 6.8
| Garancia: | 24 hónap |
