Leírás és Paraméterek
Memory
8GB GDDR7, 128bit, 28Gbps, 1750MHz, 448GB/?s
clock Base
2280MHz (Standard-Profile)
clock Boost
2625MHz (Standard-Profile), 2640MHz (OC-Profile)
overclock
+143MHz Boost (OC-Profile), +128MHz Boost (Standard-Profile)
Cooling
2x Axial-fan (100mm) with 0dB-zero-fan-mode
TDP/TGP
145W (NVIDIA), max. 155W (MSI)
AI-Computing power
614 TOPS (FP4 sparse), 307 TOPS (FP4 dense), 307 TOPS (FP8 sparse), 153.5 TOPS (FP8 dense), 153.5 TOPS (FP16 sparse), 76.75 TOPS (FP16 dense)
GPU-Computing power
20.28 TFLOPS (FP16), 20.28 TFLOPS (FP32), 0.32 TFLOPS (FP64)
Power connections
1x 8-Pin PCIe
Connectors
1x HDMI 2.1b, 3x DisplayPort 2.1b UHBR20
Interface
PCIe 5.0 x16 (x8)
Special features
AI-acceleration, Taktprofile (extreme Performance), LED lighting (RGB), Backplate, NVIDIA GeForce SFF-Ready, Graphics Cards-Mounting
total height
Triple Slot
Dimensions
248x135x41mm (LxWxH), Weight: 649g
Type
PCIe card (full height)
PCI slot bracket
full height
Chip-data
Chip-Architecture
Blackwell (from 2025/?Q1)
Chip-title
GB206-250-A1
Chip-Configuration
30SM (3840SP /? 120TMU /? 48ROP), 30 RT Cores, 120 Tensor Cores, 32MiB L2 cache
Chip-Manufacturing Process
TSMC 5nm "NVIDIA 4N"
Chip size
181mm2, monolithisch, 21.9 Mio. Transistoren
Chip-functions
Raytracing (4th Gen NVIDIA RTX, 48 TFLOPS), NVIDIA Tensor (5th Gen, 76.75 TOPS), HDCP 2.3
API-support
DirectX 12 Ultimate (12_2) /? CUDA 12.8 /? Vulkan 1.3 /? OpenCL 3.0 /? OpenGL 4.6 /? Shader Model 6.8
Transcoding-Engine
1x NVENC (9th Gen, max. Sessions: 8), 1x NVDEC (6th Gen), Info
encoding
AV1, H.265 (4K YUV 4:2:0 /? 4K YUV 4:4:4 /? 4K Lossless /? 8K /? HEVC 10bit support /? HEVC B Frame support), H.264 (YUV 4:2:0 /? YUV 4:4:4 /? Lossless)
decoding
AV1 (8bit /? 10bit), H.265 (8bit 4:2:0 /? 10bit 4:2:0 /? 12bit 4:2:0 /? 8bit 4:4:4 /? 10bit 4:4:4 /? 12bit 4:4:4), H.264, VP9 (8bit /? 10bit /? 12bit), VP8, VC-1, MPEG-2, MPEG-1
| Chipset típus | GeForce RTX 5060 |
| Garancia: | 36 hónap |
