Leírás és Paraméterek
Cores
20 (8C+12c)
Threads
20 (8+12)
Turbo Clock
5.50GHz (Turbo Boost Max 3.0), 5.40GHz (P-Core), 4.60GHz (E-Core)
Base Clock
3.90GHz (P-Core), 3.30GHz (E-Core)
TDP
125W (Processor Base Power), 250W (maximum Turbo Power)
Graphics
no
Socket
Intel 1851 (LGA1851)
chipset suitability
Z890
Codename
Arrow Lake-S
Architecture
Lion Cove (P-Core) + Skymont (E-Core)
Manufacturing Process
TSMC 3nm
L2 cache
36MB (8x 3MB + 12x 1MB)
L3 cache
30MB
Memory controller
Dual Channel DDR5, max. 192GB
Memory compatibility
max. DDR5-5600 UDIMM (PC5-44800, 89.6GB/?s), max. DDR5-6400 CUDIMM (PC5-51200, 102.4GB/?s)
ECC support
no
SMT
no
Remote management
no
Unlocked
yes
CPU-Features
AES-NI, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.5, Idle States, Instruction set 64bit (Intel 64), ISM, MBEC, OS Guard, Secure Key, Speed shift, SSE4.1, SSE4.2, Thermal Monitoring, Thread Director, Thunderbolt 4, TVB, TXT, VMD, VT-d, VT-x, VT-x EPT, XD bit
Scalability
1 socket (1S)
PCIe Lanes
24x PCIe 5.0 (available: 20)
chipset Interface
DMI 4.0, 16GT/s (PCIe 4.0 x8)
iGPU-Architecture
Xe-LPG /? Gen 12.7
NPU-Computing power
13 TOPS (Intel AI Boost)
Scope of Delivery
without CPU cooler
Launch
2024/?Q4 (24.10.2024)
Segment
desktop (Mainstream)
Stepping
B0, Spec Code: SRQCU
Max Temperature
105°C (Tjunction)
