Leírás és Paraméterek
ores
20 (8C+12c)
Threads
20 (8+12)
Turbo Clock
5.30GHz (Turbo Boost Max 3.0), 5.20GHz (P-Core), 4.60GHz (E-Core)
Base Clock
2.40GHz (P-Core), 1.80GHz (E-Core)
TDP
65W (Processor Base Power), 182W (maximum Turbo Power)
Graphics
yes (Intel Graphics)
Socket
Intel 1851 (LGA1851)
chipset suitability
B860, H810, W880, Z890
Codename
Arrow Lake-S
Architecture
Lion Cove (P-Core) + Skymont (E-Core)
Manufacturing Process
TSMC 3nm
L2 cache
36MiB (8x 3MiB + 3x 4MiB)
L3 cache
30MiB
Memory controller
Dual Channel DDR5, max. 256GB
Memory compatibility
max. DDR5-5600 UDIMM (PC5-44800, 89.6GB/?s), max. DDR5-6400 CUDIMM (PC5-51200, 102.4GB/?s)
ECC support
yes
SMT
no
Remote management
yes (Intel vPro, Intel vPro Enterprise)
Unlocked
no
CPU-Features
AES-NI, AMT, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.5, Hardware Shield, Idle States, Instruction set 64bit (Intel 64), ISM, MBEC, One-click Recovery, OS Guard, RPE, Secure Key, SIPP, Speed shift, SSE4.1, SSE4.2, TDT, Thermal Monitoring, Thread Director, Thunderbolt 4, total Memory encryption - Multi Key, TVB, TXT, VMD, VT-d, VT-rp, VT-x, VT-x EPT, XD bit
Scalability
1 socket (1S)
PCIe Lanes
24x PCIe 5.0 (available: 20)
chipset Interface
DMI 4.0, 16GT/s (PCIe 4.0 x8)
iGPU-Model
Intel Graphics
iGPU-Clock
0.30-1.95GHz
iGPU-Units
4Xe/?64EU/?512SP
iGPU-Architecture
Xe-LPG+
iGPU Interface
DP 2.1 UHBR20 (7680x4320@60Hz), eDP 1.4b (3840x2400@60Hz), HDMI 2.1 (7680x4320@60Hz)
| Garancia: | 36 hónap |
